ASRock 1xSKT AM4, AMD Ryzen, B550, SATA, 1xM.2, 4x1GbE, IPMI
מק"ט: B550D4-4L
תכונות עיקריות:
- ATX (12"x 9.6")
- תמיכה במעבדים שולחניים מסדרת Ryzen 5000 של AMD
- 4 חריצי DIMM (2DPC), תומך ב-DDR4 ECC/non-ECC UDIMM
- 1 PCIe4.0 x8, 1 PCIe4.0 x4
- 1 M.2 (PCIe3.0 x4 או SATA 6Gb/s)
- 1 OCP 2.0 מחבר ביניים A (PCIe3.0 x8)
- 4 RJ45 (1GbE) מאת Intel® i210
- 6 SATA 6Gb/s
- HDMI
- ניהול מרחוק (IPMI)
- קישור לאתר היצרן
מפרטמידע נוסף
סה"כ מחיר: 2,092 ₪ כולל מע"מ
עלות משלוח: 35 ₪
קניה בטוחה
תשלום: עד 12 תשלומים ללא ריבית
זמן אספקה: אספקה בתיאום מראש
אחריות: אחריות מול רוניטק על פי אחריות יצרןPart number: B550D4-4L
Vendor: ASRock
Categories: AMD Ryzen
Category: Server
Form Factor: ATX
CPU Socket: PGA 1331 (Socket AM4)
Num of CPU sockets: 1
Chipset: B550
Memory Type: DDR4 ECC/non-ECC UDIMM
Num of DIMM's: 4
ASRock B550D4-4L, 1xSKT AM4, AMD Ryzen, B550, SATA, 1xM.2, 4x1GbE, IPMI
- ATX (12"x 9.6")
- Supports AMD Ryzen 5000 Series Desktop Processors
- 4 DIMMs
- 1 PCIe 4.0 x16, 1 PCIe 4.0 x4
- 4 RJ45 (1GbE)
- 6 SATA 6Gb/s
- 1 M.2
- HDMI
- AST2500 Remote management (IPMI)
Specifications
| Physical Status | |
| Form Factor | ATX |
| Dimensions | 12x 9.6 Inch (305x 244 mm) |
| Processor System | |
| CPU | AMD Ryzen™ 5000 G-Series Desktop Processors with Radeon™ Graphics AMD Ryzen™ 5000 Series Desktop Processors AMD Ryzen™ 4000 G-Series Desktop Processors with Radeon™ Graphics AMD Ryzen™ PRO 5000, 4000 and 3000 Series* Desktop Processors 3rd Gen AMD Ryzen™ Desktop Processors * Not compatible with AMD Ryzen™ 3000 series processors with Radeon™ Graphics |
| Socket | AM4 PGA 1331 |
| Chipset | AMD B550 |
| System Memory | |
| Capacity | 4 DDR4 DIMM slots |
| Type | DDR4 288-pin ECC*/non-ECC UDIMM * For AMD Ryzen Desktop Processors with Radeon Graphics, ECC support is only with Processors with PRO technologies. |
| DIMM Size Per DIMM | up to 32GB per DIMM |
| DIMM Frequency | up to 3200 MT/s |
| Voltage | 1.2V |
| Expansion Slot | |
| PCIe x 16 | SLOT6: PCIe x16 (PCIe4.0 x16) |
| PCIe x 8 | SLOT4: PCIe x8 (PCIe4.0 x4) |
| Storage | |
| SATA Controller | AMD B550 (4 SATA 6Gb/s; RAID 0/1/10): 4 SATA 7-pin |
| Additional Storage Controller | ASM1061 (2 SATA6Gb/s): 2 SATA 7-pin |
| M.2 slot | 1 M-key (PCIe3.0x4 or SATA 6Gb/s); support 22110/2280/2242 form factor |
| Ethernet | |
| Additional GbE Controller | 4 Intel® i210: 4 RJ45 (1 GbE) |
| Management | |
| BMC Controller | ASPEED AST2500 |
| IPMI Dedicated GLAN | 1x Realtek RTL8211E for dedicated management GLAN |
| Graphics | |
| Controller | ASPEED AST2500: 1 DB15, 1 (15-pin) header AMD Ryzen Desktop Processors with Radeon Graphics: 1 HDMI |
| Rear Panel I/O | |
| HDMI | 1 |
| VGA Port | 1 DB15 |
| USB 3.2 Gen1 Port | 2 Type-A |
| USB 3.2 Gen2 Port | 2 Type-A |
| Lan Port | 4 RJ45 (1GbE) |
| Dedicate LAN | 1 dedicated IPMI |
| Serial Port | 1 DB9 |
| UID Button/UID LED | 1 |
| Internal Connector | |
| COM Header | 1 |
| Front Lan LED Connector | 1 for LAN3/LAN4 |
| Auxiliary Panel Header | 1 (18-pin): chassis intrusion, system fault LED, LAN1/LAN2 activity LED, locate, SMBus |
| TPM Header | 1 (17-pin, LPC), 1 (13-pin, SPI) |
| Thermal Sensor Header | 1 |
| IPMB Header | 1 |
| VGA Header | 1 |
| PMBus CONN | 1 |
| Buzzer | 1 |
| Fan Header | 6 (6-pin) |
| USB 3.2 (Gen1) Header | 1 (19-pin) support 2 USB3.2 Gen1 |
| USB 2.0 Header | 1 (9-pin) support 2 USB2.0 |
| Type A USB 3.2 (Gen1) Port | 1 |
| System Panel | 1 (9-pin): power switch, reset switch, system power LED, HDD activity LED |
| Speaker Header | 1 |
| BMC_SMB Header | 1 |
| Power Connector | 1 (24-pin, ATX main power), 1 (8-pin, ATX 12V), 1 (4-pin, ATX 12V) |
| Clear CMOS | 1 contact pads |
| Onboard LED | |
| Standby PWR LED 5vsb | 1 |
| 80 Debug Port LED | 1 |
| Fan Fail LED | 6 |
| System BIOS | |
| BIOS Type | AMI UEFI BIOS; 256 Mb (32MB) SPI Flash ROM |
| BIOS Features | Plug and Play, ACPI 5.1 compliance wake up events, SMBIOS 2.3 |
| Hardware Monitor | |
| Temperature | CPU, DDR, MB, Card Side, FCH, TR1 sensing |
| Fan | Fan Tachometer CPU Quiet Fan (Allow Chassis Fan Speed Auto-Adjust by CPU Temperature) Multi-Speed Control |
| Voltage | 3VSB, 5VSB, VCPU, VSOC, VCCM, APU VDDP, 1.05V_PROM_S5, 2.5V_PROM, 1.05V_PROM_RUN, BAT, 3V, 5V, 12V |
| Environment | |
| Temperature | Operation temperature: 10°C ~ 35°C / Non operation temperature: -40°C ~ 70°C |
