Teltonika TRB245 Industrial LTE Cat 4 Gateway

Product description

Small and durable industrial LTE Cat 4 Gateway equipped with a number of Input/Output, Serial, Ethernet ports.

Number of features makes this Gateway perfect in application where legacy and modern industrial equipment
must be integrated in one system.

Package contains

• Device
• LTE antenna (SMA male)
• GNMS antenna (SMA male) - 3m cable
• 16pin system connector
• Power adapter
• Mounting key
• Ethernet cable 1,5m
• QSG




  Technical parameters

  Wireless features

  Wireless frequency : 2G (GSM), 3G (GSM), LTE

  Connectors and Interfaces

  RF connectors : (2) SMA male

  LAN speed : (1) 10/100Mbps

  Serial port : RS-232, RS-485

  SIM slot : Yes

  SIM slots quantity : 2

  Power

  Power type : DC terminal

  Max. power consumption [W] : 5

  Power via connector/terminal : 9 .. 30V DC

  Physical characteristics

  Buttons : Reset

  Operating temperature [°C] : -40 up to 75

  Weight [g] : 165

  Width [mm] : 83

  Height [mm] : 25

  Depth [mm] : 74

  Hardware

  CPU : QCA9531

  CPU frequency [MHz] : 650

  Internal storage [MB] : 16

  RAM [MB] : 64

  Software

  Operating system : RutOS (OpenWrt based Linux OS)
