Product description

Thanks to its very strong configuration, it is the perfect device for professionals in busy locations.
There is 4x SFP+ with speed 1/10 Gbps and 13x 10 / 100 / 1000Mbps ethernet, console port type RJ45, 4 fans,
2 redundant power supplies with input voltage 100 - 240 V and M.2 PCI-e slot for SSD up to 8 TB.

RouterOS v7 level 6 is pre-installed, offering 128 MB of internal storage and 16 GB of DDR4 RAM.
The maximum power consumption of the device is maintained at an acceptable 72 W with connected peripherals.
Thanks to the new RouterOS v7, the router has up to 6 times higher performance when loading BGP.

Equipment

• (4) 1G/10G SFP+
• (13) 10 / 100 / 1000Mbps Ethernet
• (1) console RJ45 port
• Processor AL731400, frequency 2 GHz, ARM 64bit
• 16GB RAM (DDR4)
• Storage 128 MB, NAND + M.2 PCI-e slot (unmounted)
• RouterOS v7, Level 6 operating system
• Dimensions 443 x 199 x 44 mm
• (4) 40 x 40mm fans

Package Contents

• (1) Devices
• (2) Power cord
• (1) 19 "rack mounts




  Technical parameters

  Connectors and Interfaces

  M.2 slots : 1

  Multiple WAN : Yes

  LAN speed : (13) 10/100/1000Mbps

  Gigabit LAN : Yes

  Optical interfaces : (4) 1G/10Gbps

  Serial port : RJ45

  Power

  Power type : Mains power (230V)

  Redundant power supply : Yes

  Max. power consumption [W] : 60

  Power via connector/terminal : 230V AC

  Physical characteristics

  Design : Rackmount

  "U" positions : 1

  Fans : (4) 40 x 40 mm

  Chassis design : Metal

  Buttons : Reset, mode

  Operating temperature [°C] : -20 up to 60

  Width [mm] : 443

  Height [mm] : 44

  Depth [mm] : 199

  Hardware

  CPU : AL73400

  CPU frequency [MHz] : 2000

  CPU cores : 16

  Internal storage [MB] : 128

  RAM [MB] : 16384

  Software

  Operating system : RouterOS - L6

  IPv6 support : Yes

  Default IP address : 192.168.88.1

  Default login and password : admin / -
